OpenImage

Module:	FoundationLite

Removes small bright structures from an image (or fills in dark ones) by applying consecutive erosion and dilation.

E.g. removal of the "salt" component of salt-and-pepper noise.

Name	Type	Range	Description
inImage	Image		Input image
inRoi	Region *		Range of outImage pixels to be computed
inSourceRoi	Region *		Range of inImage pixels to be considered in computations
inBorderColor	Pixel *		Color of the imaginary pixels outside the image boundaries
inKernel	KernelShape		Kernel shape
inRadiusX	Integer	0 -	Nearly half of the kernel's width (2*R+1)
inRadiusY	Integer *	0 -	Nearly half of the kernel's height (2*R+1), or same as inRadiusX
outImage	Image		Output image
diagKernel	Region		Kernel shape

Description of usage of this filter can be found in examples and tutorial: Pattern Cutting.

This operation is optimized for SSE2 technology for pixels of types: all formats (when inSourceRoi = NIL and inBorderColor = NIL).

This operation supports automatic parallelization for multicore and multiprocessor systems.

This filter can throw an exception to report error. Read how to deal with errors in Error Handling.

List of possible exceptions:

Error type	Description
DomainError	Region exceeds an input image in OpenImage.

This filter is available on Basic Complexity Level.
